MAIN KEV PAB:
Vaub kib | Cov menyuam pob coj ntsia hlau | Yaskawa servo lub cev muaj zog |
Lub nti 15 nti kov lub computer | Coj qhia kev tsheb nqaj hlau | Ob chav hydraulic |
MAIN TSHWJ XEEB
QAUV | SQZ-137CTN KL |
Txiav dav (hli) | 1370 |
Max.cutting qhov siab (hli) | 165 |
Max.cutting ntev (hli) | 1450 |
Lub cev muaj zog loj (kw) | 5.5 |
Lub cev hnyav (kg) | 4700 |
Dav nrog toj (hli) | 2870 |
Tsis muaj toj (hli) | 2385 |
Tshuab siv hluav taws xob | 2785 |
Tshuab qhov siab | 1650 |
Pem hauv ntej rooj ntev (hli) | 735 |
Qhov siab cov lus (hli) | 900 |
Clamp siab min (dan / bs) | 150 |
Max (dan / bs) | 5500 |
Riam riam (hli) | 13.75 |
Sib tsoo cia (hli) | 60 |
Yog tsis muaj qhov tsis muaj clamp (hli) | 25 |
Nrog cuav clamp (hli) | 95 |
Txiav ceev (hli) | 45 |
Voltage (peb-theem) (v) | 361-339 |
Packing loj (L * W * H) (hli) | 2950*1550*2000 |
COV LUS COG LUS HAUV COMPUTER:
(1)Lub vaj huam sib luag siv siv 15 nti kov ntsuas, koj tuaj yeem kho cov xim los ntawm koj tus kheej.
(2)Lawv muaj cov xim zoo (25600), lawv cov peev xwm ncav cuag 170 pab pawg, txhua pab pawg muaj 250 txiav, Nws lub sijhawm cia yuav ncav cuag 300,000 teev.
(3)Lub hom lus ntau lus qhib ua haujlwm, xws li Suav, Askiv, Spanish ...
(4)Nws muaj luminous shortcut yuam sij los xyuas kom lub siab ruaj khov.
APPARATUS TSI LWM LUB SYSTEM:
(1)Txais yuav Switzerland ABB, German MULLER, Nyiv OMRON.
(2)Cov tshuab cua yog los ntawm TAIWAN GELING
COV NTAWV LOS NROG LUB CWJ PWM:
(1)Cov menyuam pob coj ntsia hlau: TAIWAN TBI
(2)Coj qhia ob tog kev: TAIWAN TBI
LUB COG LUS HYDRAULIC:
(1)Adjustable-pressure ob-hydraulic system (ntawv nias thiab txiav ob leeg los ntawm hydraumatic)
(2)ua ke valve los ntawm German, ISO pom zoo rau cov tshuab hydraulic.
KEV RUAJ NTSEG uas muaj kev tiv thaiv zoo:
(1)Tshaj tawm thiab meej infrared tiv thaiv cuab yeej los ntawm Shanghai Zhonghu photocell Tswj uas mus txog cov qauv CE.
(2) Blade-Hloov Ntaus Cov Khoom Siv nrog kev nyab xeeb thiab yooj yim.
(3)Huab cua cushion thiab chromeplating platform ntawm photoelectricity tiv thaiv lub tshuab.
(4)Underlay cutter thav duab.
(5)Lub kaw daim ntawv poom ncej.
(6)Lub tshuab kaw, kev tiv thaiv kev nyab xeeb, khawm kev nyab xeeb thiab lub teeb daim phiaj.
(7)Qhov txiav txiav feem siv cov cab.
9.NTIM THIAB SHIPPING：
(1)Ntim sab hauv yuav yog hlau ncej:Nws ntau ruaj khov los zam kev co thiab kev puas tsuaj.
(2)Ntim sab nrauv tuaj yeem yog rooj plaub ntoo:Cov ntaub ntawv ntoo yog cov ntawv mos muag tuaj yeem txo kev puas tsuaj los ntawm kev cuam tshuam
(3)Waterproof yas:Khaws cov khoom kom qhuav thiab zam kom tsis txhob ntxooj
(4)Peb kuj lees txais customized txog pob
FAQ:
1. Q: Koj puas yog cov chaw tsim khoom, tuam txhab lag luam lossis lub tuam txhab thib peb?
A: Peb yog cov chaw tsim khoom, nyob hauv Beiyu Industrial Zone, Ruian, Zhejiang xeev, Suav. Zoo siab txais tos tuaj xyuas peb lub tuam txhab.
2. Q: Koj lub Hoobkas ua li cas txog kev tswjhwm zoo?
A: 1) Txhua yam khoom siv raw khoom uas peb tau siv yog kev tiv thaiv ib puag ncig
2) Cov neeg ua haujlwm txawj txaus saib xyuas txhua cov ntsiab lus ntawm kev tsim cov khoom siv thiab txheej txheem
3) Lub chaw tswj xyuas khoom zoo yog tshwj xeeb ua lub luag haujlwm zoo hauv txhua qhov txheej txheem
Peb tau khaws cia muab cov khoom lag luam zoo los ntawm kev tshaj tawm cov thev naus laus zis rau ntau tshaj 20 xyoo, thiab peb cov khoom kuj tau dav xa mus rau ntau lub teb chaws suav nrog Russia, Middle East, Africa, Southeast Asia, thiab lwm yam, uas tau ua rau peb muaj koob npe nrov ntawm cov cov qhua tuaj noj mov.
3. Q: Cov nqe lus them nqi yog dab tsi?
A: T / T, nws yog 30% tso nyiaj vim yog tso khoom thiab 70% tshuav nyiaj ua ntej xa khoom.
4. Q: Ua li cas txog qhov kev pab cuam tom qab muag?
A: 1) TM online rau 24 teev, kuj hu los ntawm email, skype, whatsapp, thiab lwm yam.
2) Yuav kom daws cov teeb meem nrog cov yeeb yaj kiab / duab.
3) Ib xyoos lav rau cov khoom seem hloov.
